SF (304.8mm and Up)
This gasketed, flush cover is designed to offer multi-directional movement in exterior vertical wall applications. The system includes a primary seal, which is available in multiple colour options, and a secondary seal to ensure weather tightness. Joint sizes range from 50.8mm (2") to 609.6mm (24"). Contact the factory for larger sizes or custom applications.
We’re here to help.
Want assistance? It’s easy to get in touch with us - just click the button below.
Many of our product solutions offer choices for customisation, and we would love to talk you through your options. Let’s start (or continue) the conversation today!
Interested in this Product?
We would love to help you! For more information and to purchase, please contact us by requesting a quote below and we will be in touch with you shortly.
We’re here to help.
Want assistance? It’s easy to get in touch with us - just click the button below.
Many of our product solutions offer choices for customisation, and we would love to talk you through your options. Let’s start (or continue) the conversation today!
Finishes
-
#232 White
-
#270 Greige
-
#136 Gray
-
#108 Black
-
#764 Platinum
Gasket Colours
Performance Data
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| SF-700 | 7.00" (178 mm) | 2.50" (64 mm) | 10.50" (267 mm) | 7.00" (178 mm) | N/A | N/A |
| SF-800 | 8.00" (203 mm) | 2.50" (64 mm) | 12.00" (305 mm) | 8.00" (203 mm) | N/A | N/A |
| SF-900 | 9.00" (229 mm) | 2.50" (64 mm) | 13.50" (343 mm) | 9.00" (229 mm) | N/A | N/A |
| SF-1000 | 10.00" (254 mm) | 2.50" (64 mm) | 15.00" (381 mm) | 10.00" (254 mm) | N/A | N/A |
