ASM
This surface-mounted metal wall and ceiling cover is designed for interior applications where low maintenance or tamper-resistant applications are desired. The free-floating aluminium centre plate spans the joint and slides over the surface of the wall or ceiling to allow movement when required. The cover can be painted to match nearly any finish and is available in multiple metal finishes. Joint sizes range from 25.4mm (1") to 101.6mm (4"). Contact the factory for larger sizes or custom applications.
We’re here to help.
Want assistance? It’s easy to get in touch with us - just click the button below.
Many of our product solutions offer choices for customisation, and we would love to talk you through your options. Let’s start (or continue) the conversation today!
Interested in this Product?
We would love to help you! For more information and to purchase, please contact us by requesting a quote below and we will be in touch with you shortly.
We’re here to help.
Want assistance? It’s easy to get in touch with us - just click the button below.
Many of our product solutions offer choices for customisation, and we would love to talk you through your options. Let’s start (or continue) the conversation today!
Finishes
-
Medium Bronze
-
Dark Bronze
-
Black
Powder Coat Finishes
NOTES:
- (Aluminum Covers Only – Not recommended for floor cover applications)
-
Clear Anodize
Standard
Performance Data
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| ASM-100 | 1.00" (25 mm) | 0.38" (10 mm) | 1.50" (38 mm) | 3.13" (80 mm) | N/A | N/A |
| ASM-200 | 2.00" (51 mm) | 0.38" (10 mm) | 3.00" (76 mm) | 4.63" (118 mm) | N/A | N/A |
| ASM-300 | 3.00" (76 mm) | 0.38" (10 mm) | 6.00" (152 mm) | 7.63" (194 mm) | N/A | N/A |
| ASM-400 | 4.00" (102 mm) | 0.38" (10 mm) | 6.00" (152 mm) | 7.63" (194 mm) | N/A | N/A |
| ASMC-100 | 1.00" (25 mm) | 0.50" (13 mm) | 1.50" (38 mm) | 1.88" (48 mm) | N/A | N/A |
| ASMC-200 | 2.00" (51 mm) | 0.50" (13 mm) | 3.00" (76 mm) | 3.38" (86 mm) | N/A | N/A |
| ASMC-300 | 3.00" (76 mm) | 0.50" (13 mm) | 6.00" (152 mm) | 6.38" (162 mm) | N/A | N/A |
| ASMC-400 | 4.00" (102 mm) | 0.50" (13 mm) | 6.00" (152 mm) | 6.38" (162 mm) | N/A | N/A |
| Model | Joint Width | Min Opening | Max Opening | Exposed Surface | Blockout Width | Blockout Height |
|---|---|---|---|---|---|---|
| ASM-100S/B | 1.00" (25 mm) | 0.38" (10 mm) | 1.50" (38 mm) | 3.13" (80 mm) | N/A | N/A |
| ASM-200S/B | 2.00" (51 mm) | 0.38" (10 mm) | 3.00" (76 mm) | 4.63" (118 mm) | N/A | N/A |
| ASM-300S/B | 3.00" (76 mm) | 0.38" (10 mm) | 6.00" (152 mm) | 7.63" (194 mm) | N/A | N/A |
| ASM-400S/B | 4.00" (102 mm) | 0.38" (10 mm) | 6.00" (152 mm) | 7.63" (194 mm) | N/A | N/A |
| ASMC-100S/B | 1.00" (25 mm) | 0.50" (13 mm) | 1.50" (38 mm) | 1.88" (48 mm) | N/A | N/A |
| ASMC-200S/B | 2.00" (51 mm) | 0.50" (13 mm) | 3.00" (76 mm) | 3.38" (86 mm) | N/A | N/A |
| ASMC-300S/B | 3.00" (76 mm) | 0.50" (13 mm) | 6.00" (152 mm) | 6.38" (162 mm) | N/A | N/A |
| ASMC-400S/B | 4.00" (102 mm) | 0.50" (13 mm) | 6.00" (152 mm) | 6.38" (162 mm) | N/A | N/A |
